The explosion-proof solenoid used in this product is designed for environments where explosive gas mixtures may be present inside explosion-proof valves, thereby preventing the ignition of hazardous gases in the external environment. The solenoid’s enclosure is capable of withstanding the explosion pressure generated by internal explosive gas mixtures and prevents the propagation of internal explosions to surrounding explosive mixtures.
MODEL INSTRUCTION
| Name | Model Examples | Specifications | Model Description |
| Explosion-proof solenoid directional control valve | DS-01-3C2-D24-GB4–30 | 01/03 | GB4: For use in hazardous areas GB12: For use in mines |
| Explosion-proof electro-hydraulic directional control valve | DSHG-04-3C2-E-D24-GB4-30 | 03/04/06/10 | |
| Explosion-proof electromagnetic relief valve | B-2B3B-D24-GB4-30 | 03/06 |
TECHNICAL FEATURE
01. High explosion-proof rating, high safety factor
02. Comprehensive product range; users can select valves with different explosion-proof ratings according to specific application scenarios
SPECIFICATION
| Model | Maximum Operating Pressure (MPa) | Maximum Flow Rate (L/min) |
| DSG-01 | 31.5 | 63 |
| DSG-03 | 31.5 | 120 |
| DSHG-03 | 25 | 160 |
| DSHG-04 | 31.5 | 300 |
| DSHG-06 | 31.5 | 500 |
| DSHG-10 | 31.5 | 1100 |
APPLICATION AREA
Explosion-proof valves are primarily used in hydraulic systems operating in hazardous explosive gas environments.
